NO.6 เครื่องทำความสะอาดมุม (CNCSQJ-CNC-120)

/ / mechine

Corner Cleaning Machine CNC

Function:

For profile welding seam cleaning.

Features:

  • Two axis computer control system.
  • Imported servo motor drive system, computer control system, solenoid valve,  air source disposer and so on, ensure reliable performance and long using life.
  • Horizontal inward clamping system ensures the precision of the corner cleaning.
  • Clean outside vertical surface, up/bottom welding seam and seal rubber groove part, and also can process the lock slot of lift sash for American profile once time.
  • Can store many programs for various profile processing.
    Circular interpolation and line interpolation function to ensure the good cleaning result.
  • Can customize different knives according to different profile section for meeting different clean requirement.

Parameter:

  • Air Pressure: 0.5MPa~0.8MPa
  • Air Consumption: 80L/min
  • Input Voltage: 380V 50Hz
  • Input Power: 1.4KW
  • Main Cutter Revolution:2880r/min
  • Profile Height:30mm~120mm
  • Profile Width:20mm~120mm
  • Overall Dimension:1570mm×2670mm×2070mm
  • Weight:500kg
